LIDER flatbed trailer – Wheels underneath – Double braked axle

Description

Usable dimensions: 506 x 215 cm
Warranty: 2 years – Registration document included

A robust and professional platform, ideal for transporting vehicles, heavy materials, rubble, wood, or metal structures. Thanks to its under-frame wheels, it offers maximum usable width and excellent road stability.

Technical specifications

GVW available: 2,700 / 3,000 / 3,500 kg

Empty weight: 770 kg

Maximum payload: up to 2,730 kg

Usable dimensions: 506 x 215 cm

Total dimensions: 658 x 221 x H 65 cm

Loading height: 65 cm

Load per axle: 2 x 1800 kg

Wheels: 195/50 R13C

CP non-slip flooring

Hot-dip galvanized V-shaped arrow

Braked coupling head

Fixed pull-up bar

Hot-dip galvanized chassis

Included equipment

Hot-dip galvanized welded steel structure

Jockey wheel Ø 60

8 tie-down rings

Options and equipment available depending on version

Folding sides 35 cm (converts into a multi-purpose trailer)

60cm wire mesh risers (ideal for green spaces)

Winch

Spare wheel + bracket

Hydraulic tilting kit with manual pump + rear ramp

Powerful and versatile flatbed trailer, perfectly suited to intensive professional use as well as the demanding needs of individuals.
